HOUSEHOLD CABLE

BVR fixed wiring flexible wire (ZR-BVR)

Features: Scope of application: Applicable to AC rated voltage of 450/750V and below, it is required to have fixed installation of electrician, instrument, telecommunication equipment, power device and lighting line with flame retardant occasion. Product Features: The long-term allowable operating temperature of all types of cables should not exceed 70 °C.

INQUIRY

Product Details

Scope of application:

Applicable to AC rated voltage of 450/750V and below, it is required to have fixed installation of electrician, instrument, telecommunication equipment, power device and lighting line for flame retardant occasions.

Features:

The long-term allowable operating temperature of all types of cables should not exceed 70 °C. The laying temperature of the cable shall not be lower than 0 °C, the allowable bending radius of the cable with an outer diameter (D) of less than 25 mm shall be not less than 4D, and the allowable bending radius of the cable with an outer diameter (D) of 25 mm or more shall not be less than 6D.

Implementation standards:	GB/T2706-2008
Brand:	Cantonu Wires & Cables
Model Number:	BVR
Conductor Material:	Copper oxide free core (copper content: 99.9%)
Cores Number:	Single core
Insulator Material:	PVC
Specification:	0.75~185mm2
Nominal Voltage:	450/750V
Colors:	Red yellow yellow green bicolor blue green black

The insulation material and sheath material of BVR wire are all polyvinyl chloride. According to the different performance, the product can be divided into three categories: insulation, flame retardant and fireproof. Different classification uses are different.

model	name	Number of cores	Nominal cross section mm2	use
BVR	Copper core PVC insulated flexible wire			Power, electrical instrumentation and automation
ZR-BVR	Flame retardant copper core PVC insulated flexible wire			It is used for the fixed laying of electricians, instruments, telecommunication equipment, power equipment and lighting lines in flame retardant applications.
NH-BVR	Refractory copper core PVC insulated flexible wire			Control, monitoring circuit, power, line protection and other occasions and large-scale construction, petroleum, metallurgy, chemical, cable, ship, personnel intensive industries with high flame retardant and fire-resistant requirements
